DESCRIPTION

Basic Info

Model NO.	MPPT100/30D
Certification	ISO, CE, RoHS, SGS
Application	Solar System Controller, Charger Controller, Lighting Controller
Rated Voltage	12V/24V
System Voltage	12, 24 VDC
Nominal Power	440 W / 880 W
Open Circuit Voltage Solar Module ( at M	100V
Charge Current	30A
Ambient Temperature	-30.....+60 Degree
Weight	1300 G
Dimensions (X X Y X Z)	130 X 186 X 70 mm
Charge Voltage Absorption	Default Setting: 14.4V/28.8V
Protection Category	IP43
Transport Package	Standard Export Carton Packing
Specification	CE, RoHs, SGS, ISO9001
Trademark	Fangpusun
Origin	Zhejiang, China
HS Code	8537109090
Production Capacity	50000PCS Per Year

Packaging & Delivery

Package size per unit product 19.00cm * 13.00cm * 9.00cm Gross weight per unit product 1.200kg Lead Time 5 days (1 - 1 Pieces)
7 days (2 - 50 Pieces)
15 days (51 - 100 Pieces)
To be negotiated ( > 100 Pieces)

Product Description

1. Select system voltage 12V/24V
2. VOC: 150VDC3. Hot sale 10 years
4. Aluminum shell for heat dissipation
5. IP436. Simple operation and working principle7. Keep charging on cloudy weather.

Detailed Photos

Packaging & Shipping

Certifications

Product Parameters

Fangpusun solar charge controller		MPPT100/30D	MPPT100/50D
System voltage		12v/24v Auto Select
Maximum output current		30A	50A
Maximum PV power, 12V 1a,b)		440W (MPPT range 15V to 80V)	700W (MPPT range 15V to 70V resp.95V)
Maximum PV power, 24V 1a,b)		880W (MPPT range 30V to 80V)	1400W (MPPT range 30V to 70V resp.95V)
Maximum PV open circuit voltage		100V
Maximum efficiency		98%
Self-consumption		10mA
Charge voltage absorption		14.4 V/ 28.8V (adjustable)
Charge voltage float		13.8 V/ 27.6V (adjustable)
Charge algorithm		Multi-stage adaptive
Temperature compensation		-16mV / resp.-32mV/
Protection		Battery reverse polarity (fuse) Output short circuit / Over temperature
Operating temperature		-30 to +60 (full rated output up to 40)
Humidity		95%, non-condensing
ENCLOSURE
Colour	Black
Power terminals	13mm/AWG6
Protection category	IP43 (electronic components), IP22 (connection area)
Weight	1.5kg
Dimensions (H x W x D)	130*186*70mm
STANDARDS
Safety	EN/IEC 62109
