DESCRIPTION

Basic Info

Model NO.	OSM
Condition	New
Certification	API, ISO, CB, CE
Application	Collector Controller, Water Heater Controller, Solar System Controller, Charger Controller, Lighting Controller, Wind Controller, Solar Working Station, Voltage Controller, Thermal Controller
Rated Voltage	12V
Efficiency	99%
Current	40A/60A
Battery Voltage (VDC)	12/24/36/48 (Adaptive)
Charging Mode	MPPT Maximum Power Point Tracking
Applicable Battery Type	Lead-Acid Battery/Gel Battery/Water Battery, etc.
Charging Style	Constant Current, Constant Voltage, Floating Charg
Maximum Open Circuit Voltage	150
Start Time	Within 10s
Dynamic Response Recovery Time	≤50us
Power(W)	<1.2
Maximum Tracking Efficiency	≥99.5%
Conversion Efficiency	≥98%
Identify Voltage Range	8-64
Rated Charging Power	12V/24V/36V/48V
Screen	LCD
Transport Package	Cartons
Specification	default or customized
Trademark	Waston
Origin	China
HS Code	850440309
Production Capacity	500000 Pieces Per Year

Product Description

Type		4015	6015	4015	6015
Rated Current(A)		40	60	40	60
Battery voltage (VDC)		12/24/36/48 (adaptive)		12/24/36/48 (adaptive)
Charging mode		MPPT maximum power point tracking		MPPT maximum power point tracking
Applicable battery type		Lead-acid battery/gel battery/water battery, etc.		Lead-acid battery/gel battery/water battery, etc.
Charging style		Three stages: constant current, constant voltage, floating charge		Three stages: constant current, constant voltage, floating charge
Maximum open circuit voltage (VDC)		150		150
Start time (S)		≤10		<10
Dynamic response recovery time		≤50us		≤50us
Power(W)		<1.2		<1.2
Maximum tracking efficiency		≥99.5%		>99.5%
Conversion efficiency		≥98%		≥98%6
Identify voltage range (VDC)		8~64		8~64
Rated charging power (W)	12V	540	800	540	800
	24V	1080	1600	1080	1600
	36V	1620	2400	1620	2400
	48V	2160	3200	2160	3200
Over load voltage(VDC)		12/24		12/24
load control mode		Normally open normally closed mode/time control mode/light control mode		Normally open normally closed mode/time control mode/light control mode
Load undervoltage protection		Default 10.5VN, adjustable parameters		Default 10.5VN, adjustable parameters
Cooling sysetm		Air-cooled		Air-cooled
Screen		LCD		LCD
Protective function		Over-voltage protection, anti-reverse connection protection, over-temperature protection, load over-current protection		Over-voltage protection, anti-reverse connection protection, over-temperature protection, load over-current protection
Temp compensation system		-3mVrC/2V		-3mV^C/2V
Communication		RS485		R5485
Noise(dB)		≤50		<50
Work Temp		-20C~50C		-20C-50C
Relative humidity		0~90%RH		0~90%RH
Height(M)		0~3000		0-~3000
Dimensions(mm)		219 260*110		219*260*110
Net weight(Kg)		2.8		2.8
