Ap60c 60A 12 24 48V MPPT Solar Charge Controller

Ap60c 60A 12 24 48V MPPT Solar Charge Controller

Overview MPPT solar charge controller solar charger 60A 12V 24V 48V for home solar sytem Product Description Product Par

Send your inquiry

DESCRIPTION

Basic Info
Model NO. AP-60
Warranty 12 Months
Condition New
Certification ISO, CE
Application Solar System Controller, Charger Controller
Rated Voltage 12/24/48VDC
Display LCD+LED Display
MPPT Tracking Efficiency 99%
Charge Way Three Stage Charging
Battery Type Lead Acid Battery, Lithium Battery
Specification 340*315*180MM
Trademark ONE
Origin Foshan, China
Production Capacity 10000PCS/Month
Product Description
MPPT solar charge controller solar charger 60A 12V 24V 48V for home solar sytem

Product Description

Ap60c 60A 12 24 48V MPPT Solar Charge Controller

Ap60c 60A 12 24 48V MPPT Solar Charge Controller

Ap60c 60A 12 24 48V MPPT Solar Charge Controller

Ap60c 60A 12 24 48V MPPT Solar Charge Controller

Ap60c 60A 12 24 48V MPPT Solar Charge Controller

Product Parameters

ModelAP-50AP-60AP-80AP-100AP-120
Rated Current50A60A80A100A120A
Maximum ChargingCurrent52A62A82A102A122A
Mppt Range Operating Voltage
12VDC18VDC~80VDC
24VDC30VDC~100VDC
36VDC40VDC~100VDC
48VDC60VDC~150VDC
96VDCNot Available120VDC~200VDC
Maximum PV Array Power
12VDC700W900W1140W1400W1800W
24VDC1400W1700W2260W2800W3400W
36VDC2100W2700W3420W4200W5400W
48VDC2800W3400W4540W5600W6800W
96VDCNot Available7200W9120W11200W14400W
Battery
Supportable Battery TypeGel/SLA/AGM/Water/Lithium(lifepo4) battery
Charging ModeThree Stages: Constand Current(mppt),equalizing Charge, Floating Charge
Maximum Efficiency≥99%
Communication Portal
CommunicationRS485, available for wifi box & external control screen
Packing Details
Dimension,D*W*H(MM)360*260*190570*360*200
G.W.(KGS)4.5KGS13KGS
*Product Specifications Are Subject To Change Without Further Notice

Certifications

Company Profile

FAQ

FAQQ1: Does your company also provide other solar products except Pure Sine Wave Inverter?A1: Yes, we also provide other solar products, like MPPT Solar Controller, poly solar panel, off grid solar inverter, battery, portable solar system, solar charger and other accesoriesrelated to the solar power system.Q2: How to choose a right inverter?A2: Tell us your demand, then our sales will recommend a suitable inverter to you.
Q3: How about the delivery time?A3: 5 days for sample; 7-15 days for bulk order.Q4: What is the warranty of inverter?A4: 1 year warranty.Q5: How to solve the technical problem?A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
