MPPT 150/60 MPPT Solar Controller 60A 12V 24V 36V 48V

Package size per unit product 27.00cm * 25.00cm * 14.00cm Gross weight per unit product 3.500kg

DESCRIPTION

Basic Info

Model NO.	MPPT 150/60
Condition	New
Certification	ISO, CE, RoHS, SGS
Application	Solar System Controller, Charger Controller, Lighting Controller
Rated Voltage	12V/24V
System Voltage	12, 24, 36, 48 VDC
Nominal Power	860 W / 1720 W / 3440W
Open Circuit Voltage Solar Module ( at M	150V
Charge Current	60A
Ambient Temperature	-30.....+60 Degree
Weight	3500 G
Dimensions (X X Y X Z)	248 X 178 X 103 mm
Charge Voltage Absorption	Default Setting: 14.4V/28.8V / 43.2V/ 57.6V
Protection Category	IP43
Transport Package	Standard Export Carton Packing
Specification	CE, RoHs, SGS, ISO9001
Trademark	Fangpusun
Origin	Zhejiang, China
HS Code	8537109090
Production Capacity	50000PCS Per Year

Packaging & Delivery

Package size per unit product 27.00cm * 25.00cm * 14.00cm Gross weight per unit product 3.500kg

Product Description

MPPT 150/60 MPPT Solar Controller 60A 12V 24V 36V 48V

Fangpusun solar charge controller	MPPT150/45D	MPPT150/60D	MPPT150/70D
Battery voltage	12v/24v/48v Auto Select (software tool needed to select 36V)
Rated charge current	45A	60A	70A
Maximum PV power, 12V 1a,b)	650W	860W	1000W
Maximum PV power, 24V 1a,b)	1300W	1720W	2000W
Maximum PV power, 48V 1a.b)	2600W	3440W	4000W
Maximum PV open circuit voltage	150V absolute maximum coldest conditions, 145V start-up and operating maximum
Maximum efficiency	98%
Self-consumption	10mA
Charge voltage absorption	Default setting: 14.4 / 28.8 / 43.2 / 57.6V (adjustable)
Charge voltage float	Default setting: 13.8 / 27.6 / 41.4 / 55.2V (adjustable)
Charge algorithm	Multi-stage adaptive
Temperature compensation	-16mV / resp.-32mV/
Protection	Battery reverse polarity (fuse, not user accessible) PV reverse polarity / Output short circuit / Over temperature
Operating temperature	-30 to +60 (full rated output up to 40)
Humidity	95%, non-condensing
Data communication port and remote on-off	VE. Direct (see the data communication white paper on our website)
Parallel operation	Yes (not synchronized)
ENCLOSURE
Colour	Blue (RAL 5012)
PV terminals 2)	35mm/AWG2 (Tr models), or Dual MC4 connectors (MC4 models)
Battery terminals	35mm/AWG2
Protection category	IP43 (electronic components), IP22 (connection area)
Weight	3kg
Dimensions (H x W x D)	Tr models: 20025096mm, MC4 models: 23025095mm
STANDARDS
Safety	IEC 62109-1-2010
1a) If more PV power is connected, the controller will limit input power to thr stated maximum. 1b) PV voltage must exceed Vbat+5V for the controller to start. Thereafter minimum PV voltage is Vbat+1V 2) MC4 models: several splitter pairs will be needed to parallel the strings of solar panels
